[Therion] Custom Metapost label can't display newlines or accents
Rhys Tyers
rhystyers1 at gmail.com
Wed Apr 13 22:18:17 CEST 2022
Hello again,
I’m hoping someone can help me work out a metapost problem. The code is
available here
<https://github.com/iccaving/migovec-survey-data/blob/master/layouts/metapost/user_label.thl>
and pasted below.
None of us know anything about metapost so this is a copy/paste job of this
<https://www.mail-archive.com/therion@speleo.sk/msg07234.html> code with
some extensions. We want a label that can be turned displayed or hidden
depending on a level variable. In a system survey I turn off lots of labels
because there is lots of overlapping passage, but on more detailed ones I
turn them back on. This level thing works well.
What does not work is new lines or any non-ascii character. I have played
around with this for a while and can’t work out how to make it work.
I.e. this point:
point 174.2178 755.6161 u:label_MY -attr lvl 1 -attr text
"Hoover<br>Dam" -align tr -scale l
The <br> is not replaced by a new line and in fact the < and > are rendered
as question marks.
[image: image.png]
I think Therion does a substitution of <br> and it’s not real html or tex
but if I try to use tex in there like Hoover \\ Dam then it just errors
during compilation:
[495] (./mptextmp.mp) [496] [497] [498] (./mptextmp.mpfatal: Command
failed: etex --parse-first-line --interaction=nonstopmode
mpTXLjoJ.tex; see mpxerr.log
>> mptextmp.mp
>> mptextmp.mpx
! ! Unable to read mpx file.
l.2 btex
\mainfont \thframed {\thnormalsize Hoover \\ Dam} etex
I think this is because we are somehow not rendering with tex, and only
rendering with metapost which has a limited character set, but I really
have no idea.
Any help would be greatly appreciated!
The metapost code:
layout user_label
code metapost
def p_LABEL(expr pos)=
T:=identity shifted pos;
pickup PenD;
p:=fullcircle scaled .1u;
thclean p; thdraw p;
if known ATTR_text:
text := scantokens(ATTR_text);
thdrawoptions(withcolor .8red + .4blue);
txtm:=image(
draw txt;
interim labeloffset:=0;
label.urt(btex text etex);
);
% draw label
lab:=thelabel@#(txtm, pos);
draw lab _thop_; % use color
thdrawoptions();
bboxmargin:=0.8bp;
write_circ_bbox((bbox lab) smoothed 2);
enddef;
def p_altitude(expr pos)=
T:=identity shifted pos;
pickup PenD;
p:=(-.3u,0)--(.3u,0);
thdraw p; thdraw p rotated 90;
p:=fullcircle scaled .2u;
thclean p; thdraw p;
enddef;
vardef p_label@#(expr txt,pos,rot,mode) =
if mode=1:
thdrawoptions(withcolor .8red + .4blue);
p_altitude(pos);
% append "m" to label
picture txtm;
txtm:=image(
draw txt;
interim labeloffset:=0;
label.urt(btex \thaltitude m etex, lrcorner txt);
);
% give extra offset in case of l/r/t/b alignment
pair ctmp;
ctmp:=center thelabel@#("x", (0,0));
if (xpart ctmp * ypart ctmp)=0:
interim labeloffset:=(.4u);
else: % diagonal alignment
interim labeloffset:=(.2u);
fi;
% draw label
lab:=thelabel@#(txtm, pos);
draw lab _thop_; % use color
thdrawoptions();
bboxmargin:=0.8bp;
write_circ_bbox((bbox lab) smoothed 2);
else:
if mode=7:
interim labeloffset:=(u/8);
fi;
lab:=thelabel@#(txt, pos);
if mode>1:
pickup PenD
fi;
if mode=2:
process_uplabel;
elseif mode=3:
process_downlabel;
elseif mode=4:
process_updownlabel;
elseif mode=5:
process_circledlabel;
elseif mode=6:
process_boxedlabel;
elseif mode=7:
process_label(pos,rot); % station name
elseif mode=8:
process_filledlabel(pos, rot);
else:
process_label(pos,rot);
fi;
fi;
enddef;
vardef set_label_level (expr mylevel)=
maxl := scantokens(mylevel);
enddef;
def p_u_label_MY (expr P,R,S,A)=
T:=identity shifted P;
U:=(0,0);
save lvl;
save style;
if known ATTR_style:
style:= scantokens(ATTR_style);
else:
style :=0;
fi;
if known ATTR_text:
if known ATTR_lvl:
lvl := scantokens(ATTR_lvl);
else: lvl :=0;
fi;
if lvl < maxl+1:
U:=(S*u*(length ATTR_text)/4,S*u*(length ATTR_text)/4);
create_styled_label(ATTR_text,P,R,S,A,style);
else:;
fi;
fi;
enddef;
initsymbol("p_u_label_MY");
% https://www.mail-archive.com/therion@speleo.sk/msg07234.html
% define a custom attribute called label_mode
vardef create_styled_label (expr plaintext,P,R,S,A,defaultstyle)=
save textsize, style, thetext;
string textsize;
if S = 0.5:
textsize:="\thtinysize";
elseif S = 0.7:
textsize:="\thsmallsize";
elseif S = 1.4:
textsize:="\thlargesize";
elseif S = 2:
textsize:="\thhugesize";
else: % normal is 1
textsize:="\thnormalsize";
fi;
if known ATTR_labelstyle:
style:=scantokens(ATTR_labelstyle);
else:
style:=defaultstyle;
fi;
picture thetext;
thetext:=thTEX("\thframed {" & textsize & " " &
plaintext & "}");
if A = (-1,1):
p_label.ulft(thetext,P,R,style);
elseif A = (0,1):
p_label.top(thetext,P,R,style);
elseif A = (1,1):
p_label.urt(thetext,P,R,style);
elseif A = (-1,0):
p_label.lft(thetext,P,R,style);
elseif A = (1,0):
p_label.rt(thetext,P,R,style);
elseif A = (-1,-1):
p_label.llft(thetext,P,R,style);
elseif A = (0,-1):
p_label.bot(thetext,P,R,style);
elseif A = (1,-1):
p_label.lrt(thetext,P,R,style);
else:
p_label(thetext,P,R,style);
fi;
enddef;
endcode
endlayout
